Recommends you the best Level 2 EV chargers based on price, features, ratings and reviews. Every month we help millions of people find the best Level 2 EV chargers.
Adjustable 16-50A 240-380V Level 2 EV Charger for high-efficiency, EV charging. Buy it today! Charge your EV anytime, anywhere with the Adjustable Level 2 EV Charger. Order now!
We scoured authentic reviews of the top electric car chargers to help you decide what to buy. Comments are just for you! Here are the top-rated EV chargers to help you decide.
Best Level 2 EV Chargers product parameters:
Parameters | Requirements | |||
General Requirements | ||||
EV Charger Type | AC | |||
Charger Capacity | 3.5KW | 7KW | 11KW | 22KW |
Equipment size | L258*W165*H378(mm) | |||
L324*W199*H1461(mm) | ||||
Product Model NO. | ENC-ACB/L003P5A-S | ENC-ACB/L007A-S | ENC-ACB/L011A-S | ENC-ACB/L022A-S |
ANSI-ACB/L003P5A-S | ANSI-ACB/L007A-S | ANSI-ACB/L011A-S | ||
Mounting | Wall-Mounted/Column Type | |||
Input Requirements | ||||
AC Supply System | Single-Phase, 3 Wire AC system | Single-Phase, 3 Wire AC system(ANSI) | ||
Three-Phase, 5 Wire AC system(ENC) | ||||
Nominal Input Voltage | AC240V±15%(ANSI) | AC380V±15%(ENC) | AC380V±15% | |
AC240V±15%(ANSI) | ||||
Input Frequency | 50±3Hz | |||
Environmental Requirements | ||||
Ambient Temperature Range | -25 to 55°C | |||
Ambient Humidity | 5 to 95% | |||
Storage Temperature | -40 to 70°C | |||
Mechanical Requirements | ||||
IP Ratings | IP 55 | |||
Cooling | Natural Cooling | |||
Output Requirements | ||||
Number of Outputs | 1 | |||
Type of Each Output | AC240V±15%(ANSI) | AC380V±15%(ENC) | AC380V±15% | |
AC240V±15%(ANSI) | ||||
Single Output Max.Current | 16 Amp | 32 Amp | 16 Amp/50 Amp | 32 Amp |
User Interface & Display Requirements | ||||
Display & Touch-Screen Size | 4.3 Inches Screen | |||
User Authentication | QR Code/RFID Card /Password Login | |||
Metering Information | Consumption Units | |||
Communication Requirements | ||||
Communication between EVSE and Central server | OCPP 1.6J Protocol (Optional) | |||
Interface between Charger and CMS | Ethernet | |||
Protection & Safety Requirements | ||||
Executive Standard | IEC 62196 2017, IEC 61851 2017, SAE J1772, etc. | |||
Safety Parameters | Over Current, Under Voltage, Over Voltage, Residual Current, Surge Protection, Leakage Protection, Short Circuit, Over Temperature, etc. |
